Each month new calculation procedure will be released to boost our users performance during 3D visualisation of pressure parts.
Available COMPONENT calculator as per ASME VIII-1 will be available as an option to 3D Visualisation and detailing Tool.
Main Features
-
Design calculation to sizing new pressure vessel components
-
Rating of components of existing pressure vessel
Component Analysis capabilities
-
Design calculation to sizing new pressure vessel components
-
Internal pressure calculation in design and hydraulic test condition
-
Geometrical sizing of the component
-
MAWP calculation
-
Weight and volume calculation
-
Support stability checks
Supported Codes
Supported Elements
-
Heads (spherical, elliptical, torispherical...)
-
Shells
-
Conical sections
-
Flat welded heads
-
Flat flanged heads
-
Girth flanges
-
Nozzles (radial, inclined, hillside)
-
Support (Saddles/ Brackets/ Skirt/ Legs)
